600W Outdoor LED Zoom Ripple Floating Gobo Projector
The ripple floating gobo projector appears to be a specialized type of gobo projector designed to create the visual effect of rippling floating gobos. The projector light gives the appearance of ripple floating effects, making them suitable for various lighting and ambiance applications, such as entertainment events, themed environments, or architectural lighting.
With its high-intensity optical module, versatile color and gobo options, and an array of user-friendly features, this projector empowers lighting professionals to create breathtaking displays in any setting. Its linear zoom, multiple control modes, and outdoor durability further cement its status as a go-to lighting solution for a wide range of applications. Illuminate the night and captivate your audience with the brilliance of this remarkable lighting tool.
SOURCE
- Light Source: 600W Color WhiteLED
- Color Temperature: 6600K
- Average LED Life:20,000 Hour
POWER
- Input Voltage: 100-240VAC, 50/60Hz
- Power Consumption: 750W
OPTICAL SYSTEM
- Zoom: 5° – 50° linear electronic
- Prism:4-facet circular rotating prism
- Focus: Motorized linear focus
- Strobe: 0-25Hz variable speed, pulse and random strobe
- Dimmer: 0-100% variable linear dimming curves
COLORS
- 6 Dichoric Colorsplus open, Index / Bi-directional rotating rainbow effect
ROTATING GOBOS& RIPPLE FLOATING EFFECT
- 1 rotation gobo wheel with 6 interchangeable glassgobosplus open or 7 interchangeable glass gobos
- Interchangeable rotating / Shake / Bi-directional variable-speed rotation effect
- Glass gobo outside Φ28mm, insideΦ22mm
- 1 water ripple floating glass wheel, dynamic rotation effect
CONTROL&CONNECTION
- DMX Channel: 11CH
- Control Mode: DMX, Auto1, Auto 2, Sound,Scene
- Full Color 180° Reversible LCD
- DMX In/Out: 3 pin waterproof signal cable
- PowerIn/Out: 3 pin waterproof power cable
PHYSICAL
- Protection Rate: IP65
- Body Finish: Aluminum alloy shellwith high strength, surface blasting oxidation treatment, black and gray optional or customized color is available
- Cooling System: The heat pipe and advanced cooling system make the chip cool all the time, which maximize the chip illuminanceand delay its life greatly
WEIGHT&DIMENSION
- Net Weight:27.25kg
- Gross Weight:29.7kg
- Product Dimension: 262×329×681mm
- Package(1in1 Carton): 800×495×390mm
- (1in1 flightcase): 740×520×420mm
*The specification of Nebula 600W image projector with ripple floating subject to change without notice. All rights reserved.
- Independent R &D optical module with high intensity
- Built-in LED display for easy configuration
- 25 self-configured auto programs for convenient usage
- 6 Dichoric Colors + 7 interchangeable glass gobos(or 6 interchangeable glass gobos and open )+1 water ripple floating glass wheel
- Linear zoom from 5°to 50°
- 5 control modes for selection freely
- Vivid natural ripple floating effect
- IP65
From the dimensional drawing of 600w custom logo gobo projector light with water ripple floating, the bracket is stable and makes it freely to adjust angle. The fast lock can fix the angle of 600w image projection gobo light.
From the Illuminance chart of 600w image gobo logo projector with ripple floating, the minimum zoom is 5 degree and the maximum zoom is 50 degree.
