230W LED Spot Moving Head Light
Alkaid Spot 230 is the latest led moving head spot light designed by Nebula professional engineer team. The fixture comes out with ultra bright 230w LED with high output. The 230w led spot moving head had got a lot of attentions before it was released. Afterwards, the lighting effect of 230w spot moving head light on the press conference left a deep impression on the audiences.
One of the main features of the 230w moving head is that it can create beam effect. Therefore, it can be considered as a beam spot wash moving head. The 230w led beam spot wash moving head light features selectable beam angle including 3 degree, 8 degree and 15 degree, two prisms covering 6-facet linear prism and 8-facet prism, frost effect, full range dimmer, strobe effect and so on. This popular 230w led moving head fits 8 static gobos, 6 custom interchangeable rotating gobos, 7 colors with bi-directional rainbow effect. With the remarkable features, the 230w moving head light with spot will create awesome, fascinating, attractive lighting effect.
The fixture is with high quality and reasonable price. The speed of the fans inside can be changed automatically according to temperature. With 4 different control modes like DMX, auto, sound, manual, users can configure the 230w led moving head beam spot wash stage light well in various of conditions.
The moving head spot 230w is a very good choice for Dj, lighting designer, event planer and so on. They are active at small-medium scale live concerts, DJ Shows, schools, clubs, weddings, ceremonies, theme parks, etc.
SOURCE
● Light Source: 230W LED White
● Life: >20,000hrs
POWER
● Ballast: switching mode power supply
● Input Voltage Range: 100–240V, 50-60Hz
● Max Power Consumption: 280W
OPTICAL SYSTEM
● Beam angle: 15 °, 8 °, 3 °
● Pan: 540°(2.3sec), 16-bit resolution, Auto repositioning
● Tilt: 265° (1.8 sec), 16-bit resolution, Auto repositioning
● Prism: 6-facet linear, 8-facet prism
● Frost: 1 frost filter
● Focus: Motorized linear focus
● Dimmer: Full range 0-100% dimmer
● Strobe: Various strobe
FIXED GOBOS
● 8+ open fixed gobos
ROTATING GOBOS
● Outside ￠25.8mm, inside ￠21.5mm
● 6+ open custom interchangeable rotating gobo, indexable and gobo shaking
COLORS
● 7+open, bi-directional rainbow effect
CONTROL & CONNECTION
● DMX Channels: 16ch
● Control Modes: DMX512, Auto, Sound, Manual
PHYSICAL
● Indicate temperature info of lamp
● Fans: Fan speed auto change according to temperature
● Power In / Out: Powercon in and out
RIGGING
● Mounting Points: 4 ¼-turn locks
● 2 x Omega brackets with ¼-turn quick locks
WEIGHT & DIMENSION
● Fixture: 288X189X410mm
● Net Weight: 10.1kg
● Gross Weight: 12.25kg
● Package(1 in 1 Carton): 365X330 X470mm
*The specification of Nebula 230w led spot moving head light subject to change without notice. All rights reserved.
- High output 230W customized LED
- 3 ° ,8 °, 15 ° beam angle
- Virtual beam spot wash 3 in 1
- 7 Dichroic color+ 8 fixed gobos + 6 rotating gobos
- 6-facet linear + 8-facet prism + frost
- 4 control modes freely selection
- High cost-effective, stable and reliable performance
The outlook of Nebula 230w moving head light is fashionable from the dimensional drawing.
Nebula 230w spot moving head fits one static gobo wheel with 8 static gobos plus open, one rotating gobo wheel with 6 interchangeable rotating gobos plus open, one color wheel with 7 colors. We welcome customized gobos from customers.
- Specification
-
SOURCE
● Light Source: 230W LED White
● Life: >20,000hrsPOWER
● Ballast: switching mode power supply
● Input Voltage Range: 100–240V, 50-60Hz
● Max Power Consumption: 280WOPTICAL SYSTEM
● Beam angle: 15 °, 8 °, 3 °
● Pan: 540°(2.3sec), 16-bit resolution, Auto repositioning
● Tilt: 265° (1.8 sec), 16-bit resolution, Auto repositioning
● Prism: 6-facet linear, 8-facet prism
● Frost: 1 frost filter
● Focus: Motorized linear focus
● Dimmer: Full range 0-100% dimmer
● Strobe: Various strobeFIXED GOBOS
● 8+ open fixed gobosROTATING GOBOS
● Outside ￠25.8mm, inside ￠21.5mm
● 6+ open custom interchangeable rotating gobo, indexable and gobo shakingCOLORS
● 7+open, bi-directional rainbow effectCONTROL & CONNECTION
● DMX Channels: 16ch
● Control Modes: DMX512, Auto, Sound, ManualPHYSICAL
● Indicate temperature info of lamp
● Fans: Fan speed auto change according to temperature
● Power In / Out: Powercon in and outRIGGING
● Mounting Points: 4 ¼-turn locks
● 2 x Omega brackets with ¼-turn quick locksWEIGHT & DIMENSION
● Fixture: 288X189X410mm● Net Weight: 10.1kg
● Gross Weight: 12.25kg
● Package(1 in 1 Carton): 365X330 X470mm
*The specification of Nebula 230w led spot moving head light subject to change without notice. All rights reserved.
- Advantage
-
- High output 230W customized LED
- 3 ° ,8 °, 15 ° beam angle
- Virtual beam spot wash 3 in 1
- 7 Dichroic color+ 8 fixed gobos + 6 rotating gobos
- 6-facet linear + 8-facet prism + frost
- 4 control modes freely selection
- High cost-effective, stable and reliable performance
- Dimensional Drawing
-
The outlook of Nebula 230w moving head light is fashionable from the dimensional drawing.
- Illuminance & Lighting Effect
-
- Colors & Gobos
-
Nebula 230w spot moving head fits one static gobo wheel with 8 static gobos plus open, one rotating gobo wheel with 6 interchangeable rotating gobos plus open, one color wheel with 7 colors. We welcome customized gobos from customers.
